200w 12v 24v Dc To Ac 220v Pure sine wave power inverter

Model

B600Z

B1000Z

B1500Z

B2000Z

B3000Z

B4000Z

B5000Z

Display

LCD Display

DC Input

Rate voltage

12Vdc/24Vdc/48Vdc/60Vdc/72Vdc

Range voltage

10-15Vdc/20-30Vdc/40-60Vdc/50-75Vdc/60-90Vdc

Output

Output Voltage

110Vac or 220Vac±5%

Output Frequency

50Hz or 60Hz±0.1%

Wave

Pure Sine wave

Output Power

600W

1000W

1500W

2000W

3000W

4000W

5000W

Peak Power

1200W

2000W

3000W

4000W

6000W

8000W

10000W

Conversion Efficiency

≥90%

Protect function

Function-1

Input reverse connection protection: Fuse

Function-2

Input low voltage protection : 20Vdc±0.3V

Function-3

Recovery voltage : 24V(25.5V±0.3)

Function-4

Input high voltage protection: 30Vdc±0.3V

Function-5

Over temperature protect: 80°±5°

No-load current

0.3A

0.6A

0.7A

0.7A

1.0A

1.0A

1.0A

Over load protection

660±50W

1100±50W

1650±50W

2200±50W

3300±50W

4000±50W

5000±50W
