ASQ 630A 4P Dual Power Automatic Transfer Switch

Short Description:

Do Better Performances in Demanding Duties
Yueqing Aiso gain client trust thanks to their proven reputation for reliability, performance and long life. Electrical equipment from Yueqing Aiso are available for original equipment manufacturers (OEM) to incorporate in their own installations or for use in repair, retrofit and upgrade projects.
Why Yueqing AIso?
1,Full engineering and technical support: 3 professional manufacturers, and technical service team.
2,Quality is No1 ,our culture.
3,Quickly lead times:”Time is gold” for you and for us
4,30min fast response:we have professional team,7*20H




Product Detail

Product Tags

ASQ 630A 4P Dual Power Automatic Transfer Switch

Dual-power supply automatic transfer switch (ATS)is the latest company technology development of high-tech products.It conforms to GB/T14048/.1-2006,GB/T14048.11-2008,and also with “high-rise building fire norms” and “emergency lighting design guide” etc.It is suitable to AC 690V,rated frequency 50Hz/60Hz.

Two section automatic transfer switch,change from one power supply connect to another immediately on the intermediate open position when the switch get the switching signal.

Three sectionautomatic transfer switch when get the switching signal can change from one power supply connect to another or change from one power supply connect to the intermediate immediately or affter a preset delay time.

The class of S or L seriesswitch:PC

The front plate wiring.

If you are interested if ual power automatic transfer switch intelligent controller settings, pls contact us.



Main technical parameters



Model ASQ-630/4P
Rated working voltage Ue AC400V
Rated insulation voltage 690V
Rated impulse withstand voltage 6kA
Rated limiting short circuit current 50kA
Operating cycles(S/times) 30S
Switching time 0-99S
Welcome to contact us for other ATS model details.
Overall dimension and installation dimension   ASQ5 630A 4P Dual Power Automatic Transfer Switchi

Model Overall dimension Installation dimension Copper bar dimension
L W H L1 W1 3-Ø L2 T P
ASQ-630/4P 410 290 132 290 200 Ø7 40 5 62
