OEM/ODM Supplier Motorized Changeover Switch - ASQ 630A 4P Dual Power Automatic Transfer Switch – Aiso Detail:
ASQ 630A 4P Dual Power Automatic Transfer Switch
Dual-power supply automatic transfer switch (ATS)is the latest company technology development of high-tech products.It conforms to GB/T14048/.1-2006,GB/T14048.11-2008,and also with “high-rise building fire norms” and “emergency lighting design guide” etc.It is suitable to AC 690V,rated frequency 50Hz/60Hz.
Two section automatic transfer switch,change from one power supply connect to another immediately on the intermediate open position when the switch get the switching signal.
Three sectionautomatic transfer switch when get the switching signal can change from one power supply connect to another or change from one power supply connect to the intermediate immediately or affter a preset delay time.
The class of S or L seriesswitch:PC
The front plate wiring.
If you are interested if ual power automatic transfer switch intelligent controller settings, pls contact us.
Main technical parameters
| Model |
ASQ-630/4P |
| Rated working voltage Ue |
AC400V |
| Rated insulation voltage |
690V |
| Rated impulse withstand voltage |
6kA |
| Rated limiting short circuit current |
50kA |
| Operating cycles(S/times) |
30S |
| Switching time |
0-99S |
Welcome to contact us for other ATS model details.
Overall dimension and installation dimension
i
| Model |
Overall dimension |
Installation dimension |
Copper bar dimension |
| L |
W |
H |
L1 |
W1 |
3-Ø |
L2 |
T |
P |
| ASQ-630/4P |
410 |
290 |
132 |
290 |
200 |
Ø7 |
40 |
5 |
62 |
