OEM Factory for Current Transformer Company - LZZBJ4 35kV Post Model Current Transformer – Aiso Detail:

Summary

Yueqing Aiso LZZBJ4 35kV Post Model Current Transformer is used indoor, Usually installed in the vacuum circuit breaker for use. We can customize the level of accuracy and capacity according to the requirements of users.

LZZBJ4-35 high voltage power supply epoxy resin current transformer current transformer is epoxy resin casting fully closed product, suitable for rated frequency 50Hz or 60Hz, rated voltage 35KVpower system, for electric energy metering, current measurement and relay protection.

Type designation

 LZZBJ4 35kV Post Model Current Transformer

Outline and installation dimension

35kV Post Model Current Transformer

Technical parameter

Ratde primary current(A) Accuracy class combination Accuracy class / rated burden (VA) 4S Thermal current(kA) Rated dynamic stabiity curret(kA)
5-50 0.2S/0.5/10P10 0.2/0.5/10P10 0.2S/10P10/10P10 0.2/10P10/10P10 0.5/10P0/10P10 0.2S/0.5/10P10/0P10 0.2/0.5/10P10/0P10 02S/10P10/10P10/10P10 02/10P10/10P10/10P10 0.5/10P10/10P10/10P10 10P10/10P0/10P10 10P10/10P10/10P10/10P10 0.2S 0.2 15 3 7.5
0.5 25
10P10 50
75 0.2S 0.2 15 5 12.5
0.5 25
10P10 50
100 0.2S 0.2 15 8 20
0.5 25
10P10 50
150 0.2S 0.2 15 12 30
0.5 25
10P10 50
200 0.2S 0.2 15 16 40
0.5 25
10P10 50
300 400 0.2S 0.2 15 20 50
0.5 25
10P10 50
600 0.2S 0.2 15 31.5 80
0.5 25
10P10 50
800 1000 1200 1500 1600 0.2S 0.2 15 40 100
0.5 25
10P10 50
